Field Blasting
Sand Blasting Nozzle focuses the air-abrasive stream on steel and concrete.
EnquireSand Blasting
A sand blasting nozzle is a tool used in sandblasting, which is a process of cleaning, smoothing, or shaping a surface by forcing abrasive materials through a high-pressure stream of compressed air or water. The nozzle is part of the sandblasting gun that directs the abrasive material to the surface
Browse full product photos, component close-ups, and application views.
Review the key product specifications used for quotation and application planning.
Watch how the machine performs in real blasting and surface preparation conditions.
A sand blasting nozzle is a tool used in sandblasting, which is a process of cleaning, smoothing, or shaping a surface by forcing abrasive materials through a high-pressure stream of compressed air or water. The nozzle is part of the sandblasting gun that directs the abrasive material to the surface
Sand Blasting Nozzle is threaded or clamped onto the blast hose coupling.
The operator aims the bore at the work at the correct standoff.
The venturi or straight bore speeds air and abrasive at the exit.
The focused stream removes rust, paint, or scale in a controlled pattern.
Carbide liners are checked because wear widens the pattern and drops speed.
A worn nozzle is swapped so production rate and profile stay in spec.
It is critical to choose the proper Sand Blasting Nozzle for the right job. Make sure to examine the Air and Abrasive Consumption Chart to verify that there is enough air supply. Only use Venturi nozzles for pressure blasting equipment and portable sand blasting Machine, which has a large input diameter that tapers progressively towards the orifice diameter before flaring out at the outlet end. The abrasive velocity at the output is often greater than 700 km/h and has the highest concentration of impact of any type of nozzle.
A sand blasting nozzle is a tool used in sand blasting machine, which is a process of cleaning, smoothing, or shaping a surface by forcing abrasive materials through a high-pressure stream of compressed air or water. The nozzle is part of the sand blasting gun that directs the abrasive material to the surface being treated.
Sand blasting nozzles are made from a variety of materials, including tungsten carbide, boron carbide, ceramic, and steel. The material used for the nozzle will depend on the specific application and the type of abrasive material being used.
The size and shape of the sand blasting nozzle also affect the sand blasting machine process. The diameter of the nozzle determines the amount of abrasive material that can be delivered, while the shape of the sand blasting nozzle affects the velocity and pattern of the abrasive material.
Sand blaster nozzle can be purchased in various sizes and types to suit different applications. It's important to choose the right size and type of Sand blaster nozzle to achieve the desired results and to ensure safe and efficient operation.
Nozzles come in two essential shapes: straight bore and Venturi, with several variations of Venturi nozzles.
Venturi blast nozzles produce a broad blast pattern while increasing abrasive velocity. Venturi nozzles, which are ideal for increased sandblasting productivity when working on bigger surfaces, allow blast projects to be finished more efficiently.
Straight bore nozzles are designed for spot blasting at close range. They are ideal for cleaning small areas such as weldments, grillwork, and railings since they have small blast patterns and little over blast. If your equipment requires a non-standard nozzle, we can manufacture it for you. Please contact us if you have any particular requirements.
Wide throat nozzles are de Laval nozzles having a large throat and an extra-1/4" wide convergence portion. When used in conjunction with a sand blasting hose with a matching internal diameter (and commensurate increase in air volume), the wide throat nozzle can increase productivity by up to 15% over lengthy Distances.
These extra-long nozzles accelerate particles over a longer distance, resulting in higher exit velocities and allowing the blaster to stand further away from the surface being blasted, as well as a larger blast pattern and better production rates.
The composition of the lining inside the bore is the third factor to consider when selecting a nozzle. Harder materials are more resistant to wear, but they are more expensive to replace and are prone to cracking when handled roughly. Carbide sand blasting nozzles are classified into three categories.
This is the least lasting of the carbide nozzles, although the tungsten carbide nozzle is reasonably inexpensive and impact resistant. Slag, glass, and mineral abrasives are all suitable for blasting.
Tungsten carbide is impact resistant and robust, yet the Silicon carbide nozzle is lightweight. Reduces operator strain.
Brittle despite being extremely hard and resilient. Boron Carbide nozzle has ten times the durability of tungsten carbide.
Spray Blast is the Leading Sand blasting Nozzle Suppliers in India. Sand blasting nozzle price depends on the type of sand blaster nozzle. We also provide the sand blasting machine, portable sand blasting machine, sand blasting cabinet, sand blasting room, remote control valve, abrasive media, steel shot, steel grit, glass beads, copper slag, etc.
Compare Sand Blasting Nozzle with other models in Sand Blasting.
| Specification | Sand Blasting Stencil | This model Sand Blasting Nozzle | Abrasive Blasting Machine |
|---|---|---|---|
| Product | Sand blasting Stencil | — | Abrasive Blasting Machine |
| Material | Polyester Liner/Rubber Adhesive and Backing | Tungsten / Boron Carbide | Mild Steel |
| Material Size | 300, 350, 400, 500, 550, 600um, 1.0mm | — | — |
| Glue Thickness | 40um | — | — |
| Length(m) | 10m-20m | — | — |
| Width(cm) | 122cm, 120cm, 60cm, 30cm | — | — |
| Adhesive | ~ 35g/m² | — | — |
| Release Liner | ~ 140g/m² | — | — |
| Brand | Spray Blast | Spray Blast | Spray Blast |
| Color | Grey, Transparent Pink, Light Green | — | As per client requirement |
| Country | India | — | India |
| Packaging Type | Bubble Wrapping | — | — |
| Transport Type | Land/Sea/Air Transport | Land / Sea / Air Transport | — |
| Price Range | Rs 1000-1500/Roll | Rs 3 K - 20 k | Rs 4-8 Lakh |
| Size | — | 5 - 12 mm | — |
| Thread Size | — | 1/4" BSPT, For Y gun | — |
| Tensile Strength | — | 100-700 MPA | — |
| Usage | — | Sand Blasting Machine | — |
| Nozzle Holder | — | Aluminum | — |
| Nozzle Type | — | Long Nozzle / Short Nozzle | — |
| Country of Origin | — | Made in India | — |
| Delivery Time | — | 6-7 Days | 1-2 Weeks |
| Production Capacity | — | 4-5 | 4 Machine |
| Packaging Details | — | Polly Pack With Bubble Packing | Polly Pack With Bubble Packing |
| Machine Grade | — | — | Manual and Automatic |
| Frequency | — | — | 50Hz |
| Voltage | — | — | 440V |
| Power | — | — | 12.5hp |
| Delivery Type | — | — | Ship/Air/Land |
Typical applications for Sand Blasting Nozzle across industrial blasting, coating, and surface preparation work.
Sand Blasting Nozzle focuses the air-abrasive stream on steel and concrete.
EnquireA true bore still cuts paint when the liner is in spec.
EnquireJet speed and standoff set the anchor pattern.
EnquireShorter nozzles help in tight structural areas.
EnquireLonger hoses pair with the nozzle for large internals.
EnquireVenturi designs raise cleaning rate on open steel.
EnquireSmaller orifices slow the cut on thin plate.
EnquireA worn nozzle wastes air and widens the pattern.
