Blast Control
Remote Control Valve starts and stops abrasive flow at the operator.
EnquireSand Blasting
A remote control valve for sand blasting is a type of valve used to control the flow of abrasive media in a sandblasting system. Sandblasting is a process used to clean or prepare surfaces by forcibly propelling a stream of abrasive material against them.
Browse full product photos, component close-ups, and application views.
Review the key product specifications used for quotation and application planning.
Watch how the machine performs in real blasting and surface preparation conditions.
A remote control valve for sand blasting is a type of valve used to control the flow of abrasive media in a sandblasting system. Sandblasting is a process used to clean or prepare surfaces by forcibly propelling a stream of abrasive material against them.
Remote Control Valve is fitted in the blast air line to the pot.
The operator must keep the handle or valve actuated for blasting to run.
When held, air and media flow to the nozzle.
Letting go dumps or shuts the line so the stream stops immediately.
A broken hose or dropped handle automatically ends blasting.
The control is tested for leaks and positive shut-off before the shift.
A remote control valve for sand blasting is a type of valve used to control the flow of abrasive media in a sand blasting machine system. Sand blasting is a process used to clean or prepare surfaces by forcibly propelling a stream of abrasive material against them. The remote control valve allows the operator to control the flow of the abrasive material from a safe distance, without having to manually operate the valve at the sandblasting nozzle.
Typically, a remote control valve for sand blasting will be a pneumatic valve that is controlled by compressed air. The valve is typically mounted on the sand blasting pot, which is the container that holds the abrasive media. The remote control device can be a handheld pneumatic control switch, or it may be integrated into a more advanced sand blasting control system.
Remote control valves for sand blasting are essential for ensuring the safety of the operator and for providing precise control over the abrasive media flow rate. The operator can adjust the flow rate of the abrasive material to achieve the desired cleaning or preparation effect on the surface being treated.
The RCV remote control valve is used to control the compressed air feed to the machine as well as the air blow-out from the machine. When the abrasive blasting machine operator presses or releases the DMH handle, both control functions are activated. A damper incorporated in the delivery set is used to bleed air from the tank.
The DMH remote control handle is fastened to the sand blasting nozzle and connected to the RCV remote control valve using a dual hose.
The RCV remote control valve responds when the DMH handle is pressed. The blast machine's tank is pressurized and the abrasive blast cleaning process begins. When the DMH handle is released, the RCV remote control valve closes, the abrasive blast cleaning process terminates and the machine's tank depressurizes.
Compare Remote Control Valve with other models in Sand Blasting.
| Specification | Sand Blasting Stencil | This model Remote Control Valve | Abrasive Blasting Machine |
|---|---|---|---|
| Product | Sand blasting Stencil | — | Abrasive Blasting Machine |
| Material | Polyester Liner/Rubber Adhesive and Backing | Aluminium | Mild Steel |
| Material Size | 300, 350, 400, 500, 550, 600um, 1.0mm | — | — |
| Glue Thickness | 40um | — | — |
| Length(m) | 10m-20m | — | — |
| Width(cm) | 122cm, 120cm, 60cm, 30cm | — | — |
| Adhesive | ~ 35g/m² | — | — |
| Release Liner | ~ 140g/m² | — | — |
| Brand | Spray Blast | Spray Blast | Spray Blast |
| Color | Grey, Transparent Pink, Light Green | Black / Silver | As per client requirement |
| Country | India | India | India |
| Packaging Type | Bubble Wrapping | — | — |
| Transport Type | Land/Sea/Air Transport | Land / Sea / Air Transport | — |
| Price Range | Rs 1000-1500/Roll | Rs 9 K - 12 K | Rs 4-8 Lakh |
| Size | — | 1 x 1/4 inch | — |
| Material to be Blasted | — | Spare Parts of Sand/Shot Blasting Machine | — |
| Used With | — | Portable Sand Blasting Machine | — |
| Rust Proof | — | Yes | — |
| Finish Type | — | Polished | — |
| Delivery Time | — | 5-7 Days | 1-2 Weeks |
| Production Capacity | — | 5 | 4 Machine |
| Packaging Details | — | Polly Pack With Bubble Packing | Polly Pack With Bubble Packing |
| Machine Grade | — | — | Manual and Automatic |
| Frequency | — | — | 50Hz |
| Voltage | — | — | 440V |
| Power | — | — | 12.5hp |
| Delivery Type | — | — | Ship/Air/Land |
Typical applications for Remote Control Valve across industrial blasting, coating, and surface preparation work.
Remote Control Valve starts and stops abrasive flow at the operator.
EnquireDropping the handle ends the stream immediately.
EnquireValve position helps keep a stable air-to-abrasive mix.
EnquireControls sit in the circuit so a broken line dumps safely.
EnquireRemote valves let the nozzle man control a distant pot.
EnquirePinch valves meter media on pressure cabinets.
EnquireMedia stops without slamming a metal gate.
EnquireControl valves are stocked as critical blast-site parts.
