Repeatable Cycles
Automatic Sand Blasting Machine follows a programmed path for consistent results.
EnquireSand Blasting
Automatic Sand Blasting Machine for industrial blasting, surface preparation, fabrication, foundry, coating, and workshop requirements.
Browse full product photos, component close-ups, and application views.
Review the key product specifications used for quotation and application planning.
Watch how the machine performs in real blasting and surface preparation conditions.
The sequence below shows how Automatic Sand Blasting Machine operates, from setup through to the working result.
Automatic Sand Blasting Machine is set with part recipe, nozzles, and travel path.
Work is clamped or indexed into the blast zone.
Guns or a gantry move through the programmed pattern.
Time and pressure stay consistent from part to part.
Abrasive and dust return through reclaim and filtration.
Finished parts exit for inspection against the program standard.
The Automatic Sand Blasting Machine is powered by two stepper motors. The first motor rotates the table, while the second motor moves the gun up and down in a reciprocating motion. The workpiece is placed on the turntable and spins through the stepper motor first, and then using the second motor we may alter the position of the Sand Blasting nozzle up and down, with four switches on the control panel. We can adjust the Sand Blasting nozzle position using switches to 154, 250, 305, and 355mm. On the control panel, there is a switch that allows us to turn on and off the automatic sand blasting procedure.
We may also adjust the rotational speed of the table using the regulator switch. Begin by turning on the air compressor. and place the workpiece on the turntable into the Automated Sand Blasting Cabinet and fill it with abrasive material. The air compressor generates a massive volume of high-pressure air, which is regulated by a solenoid or ball valve. Anywhere fluid and airflow must be controlled automatically, solenoid valves are used.
An automatic sand blasting machine is a mechanical system that uses compressed air or another type of gas to propel abrasive materials, such as sand or glass beads, at high speeds to clean, polish or etch surfaces. The machine is designed to automate the sand blasting machine process, making it more efficient and precise.
Following that, a non-return valve is employed to protect the moisture separator. The ball valve is controlled manually (On/Off) by the operators. The air compressor's air enters the suction gun via the Pipe. If the Ball Valve is turned on, a vacuum is created in the gun, which causes suction. Through the cannon, abrasive materials such as aluminum oxide propellers are applied to the abrasive surface. For high-speed propelling, the air is supplied directly to the mixing tube through an air compressor. Both the blaster surface and the blaster media have resided in the cabinet.
The environment is dust-free in the automated Sand Blasting Equipment. We have a fabric bag dust collector on the backside of the Automated Blasting Cabinet to collect dust particles and micro particles that settle down and can be used as recycled abrasives. Blasting the workpiece can be accomplished in two ways: by moving the workpiece or by moving a Sand Blasting gun.
The components of an automatic sand blasting machine typically include a blasting chamber, a nozzle or gun, a media recovery system, a dust collection system, and a control panel. The blasting chamber is where the object to be sandblasted is placed. The sand blasting nozzle or gun directs the abrasive material onto the object, while the media recovery system collects and recycles the used abrasive for future use. The dust collection system captures any airborne particles generated during the sandblasting process, preventing them from escaping into the environment.
The automatic sandblasting machine has a unique design, a simple and dependable structure, easy operation, high processing efficiency, and low energy consumption.
The automated sand blaster machine is outfitted with a separator, which is used to purify the used abrasive media of pollutants, hence significantly reducing abrasive usage.
The automated sand blasting equipment electrical components are made of high quality world-renowned brand parts that are safe, dependable, and have a long service life.
Compare Automatic Sand Blasting Machine with other models in Sand Blasting.
| Specification | Sand Blasting Stencil | This model Automatic Sand Blasting Machine | Abrasive Blasting Machine |
|---|---|---|---|
| Product | Sand blasting Stencil | — | Abrasive Blasting Machine |
| Material | Polyester Liner/Rubber Adhesive and Backing | Mild Steel | Mild Steel |
| Material Size | 300, 350, 400, 500, 550, 600um, 1.0mm | — | — |
| Glue Thickness | 40um | — | — |
| Length(m) | 10m-20m | — | — |
| Width(cm) | 122cm, 120cm, 60cm, 30cm | — | — |
| Adhesive | ~ 35g/m² | — | — |
| Release Liner | ~ 140g/m² | — | — |
| Brand | Spray Blast | Spray Blast | Spray Blast |
| Color | Grey, Transparent Pink, Light Green | As per client requirement | As per client requirement |
| Country | India | India | India |
| Packaging Type | Bubble Wrapping | — | — |
| Transport Type | Land/Sea/Air Transport | Land / Sea / Air Transport | — |
| Price Range | Rs 1000-1500/Roll | Rs 6 Lakh - 40 Lakh | Rs 4-8 Lakh |
| Machine | — | Automatic Sand blasting Machine | — |
| Machine Type | — | Automatic | — |
| Compressed Air Source | — | 5-7 Bar(Kg/M) | — |
| Power Supply | — | 220V, 50Hz | — |
| Air Flow | — | 0.8-3 M^3/Min | — |
| Blasting Nozzle | — | Boron Carbide sand blasting Nozzle | — |
| Working Chamber Size | — | L1200 * W1200 * H850 mm | — |
| Use | — | Cleaning, Finishing | — |
| Delivery Time | — | 1-2 Weeks | 1-2 Weeks |
| Production Capacity | — | 4-5 | 4 Machine |
| Packaging Details | — | Polly Pack With Bubble Packing | Polly Pack With Bubble Packing |
| Machine Grade | — | — | Manual and Automatic |
| Frequency | — | — | 50Hz |
| Voltage | — | — | 440V |
| Power | — | — | 12.5hp |
| Delivery Type | — | — | Ship/Air/Land |
Typical applications for Automatic Sand Blasting Machine across industrial blasting, coating, and surface preparation work.
Automatic Sand Blasting Machine follows a programmed path for consistent results.
EnquireFixtures index parts through the blast envelope.
EnquireControlled blast cuts artwork or texture.
EnquireOperators load and unload rather than hose the cycle.
EnquireGranite and metal graphics are cut to a program.
EnquireThe machine sits in a lights-out capable cell.
EnquireSeveral nozzles share a recipe for complex parts.
EnquireRecipes are stored against part numbers.
EnquireAnswer a few questions and we will suggest a starting configuration for Automatic Sand Blasting Machine — then confirm the exact specification with our team.
What material are you blasting?
What are you removing?
Required surface finish?
Frequency of use?
Available compressor capacity (CFM)?
Desired production rate?
