Wear Protection
Powder Flame Spray Gun applies dense metallic or carbide coatings on high-wear parts.
EnquireSpray Gun
A powder flame spray gun is a type of thermal spray equipment that uses a combustion process to melt and atomize powder feedstock, which is then deposited onto a substrate to form a coating.
Browse full product photos, component close-ups, and application views.
Review the key product specifications used for quotation and application planning.
Watch how the machine performs in real blasting and surface preparation conditions.
A powder flame spray gun is a type of thermal spray equipment that uses a combustion process to melt and atomize powder feedstock, which is then deposited onto a substrate to form a coating.
The part is blasted and cleaned before Powder Flame Spray Gun is used.
Consumable is supplied into the oxy-fuel flame.
The flame melts the material at the gun nozzle.
Air or flame velocity carries droplets onto the substrate.
Some alloys are torch-fused after spray for a denser coat.
Thickness and bond are checked against the job card.
A powder flame spray gun is a type of thermal spray equipment that uses a combustion process to melt and atomize powder feedstock, which is then deposited onto a substrate to form a coating. The powder is fed into a combustion flame generated by a fuel gas and an oxidant gas mixture, which melts and atomizes the powder into fine droplets. The droplets are propelled towards the substrate by the high velocity of the gas mixture and impact onto the surface, forming a coating.
Powder flame spray guns are commonly used for surface coatings in various industries, such as aerospace, automotive, and marine, as well as for repair and maintenance applications. They can be used with a variety of materials, including metals, alloys, ceramics, and polymers, and can produce coatings with a range of thicknesses and properties.
Powder flame spray guns typically require a compressed air or gas supply for the atomization and propelling of the molten droplets. They can also require a preheating process for the substrate to ensure proper adhesion of the coating. Powder flame spray guns offer the advantage of being able to use a wider range of materials compared to wire flame spray guns, but may require additional equipment for powder handling and delivery. Overall, powder flame spray guns offer a flexible and efficient solution for a variety of coating applications.
The powder flame spray gun 5PM-II can be used for a variety of tasks. It can be used to coat a variety of materials, including self-fluxing alloys, ceramics, self-bonding materials, and traditional materials such as steels, stainless steels, bronze, aluminum-based, and nickel-based alloys. The 5PM-II is designed for portable use and incorporates a pistol-grip handle for operator comfort and safety. On request, a tool post fixture may be fitted to rest the gun during workpiece changeover or machine-mount operation. The 5PM-II models is ideal for businesses that require just periodic surfacing or when a low-cost solution is required.
Powder Flame Spray Gun 6 PM-II is used to apply coatings to tackle surface problems such as machine component repair, dimensional restoration, corrosion protection, readability, and wear resistance. These coatings are very inexpensive to run. High coating rates with low gas consumption and good deposit efficiencies can be achieved with the 6 PM - II series equipment. These firearms are very simple to operate and maintain.
We are the leading Powder Flame Spray gun manufacturers & Suppliers of 5PM-II Powder Flame Spray Gun, 6PM-II Powder Flame Spray Gun,metalizing gun, arc spray gun, flame spray gun, thermal spray wire, Babbitt wire, copper wire, aluminum wire, thermal spray powder, thermal spray booth
Compare Powder Flame Spray Gun with other models in Spray Gun.
| Specification | Tungsten Carbide Coating | This model Powder Flame Spray Gun | Electric Arc Spray Gun |
|---|---|---|---|
| Product | Tungsten Carbide Coating | — | — |
| Hardness | 2200HV | — | — |
| Melting Temperature | 2800C | — | — |
| Bond Strength | 8,500 PSI | — | — |
| Deposit efficiency, % | 48-58 | — | — |
| Brand | Spray Blast | Spray Blast | Spray Blast |
| Country of Origin | India | — | — |
| Delivery Time | 1-2 Weeks | 10-15 Days | — |
| Packaging Details | Polly Pack With Bubble Packing | — | — |
| Price Range | Rs 60k-1Lakh | Rs 45K - 5Lakh | Rs 6 Lakh - 20 Lakh |
| Type of Gun | — | Powder Flame Spray gun | Electric Arc Spray Gun |
| Grade | — | Automatic / Manual | Manual / Semi-Automatic |
| Gun Weight | — | 1.7 Kg / 1.85 Kg | — |
| Acetylene Consumption | — | 13.5 to 31.5 NLPM | — |
| Hydrogen Consumption | — | 90 to 144 NLPM | — |
| Oxygen Consumption | — | 20 to 45 NLPM | — |
| Compressed Air Consumption | — | 0.85 m3/min at 4.5 bar | — |
| Color | — | As per client requirement | As per client requirement |
| Country | — | India | India |
| Packaging Type | — | Bubble Wrapping & Box | Bubble Wrapping & Box |
| Delivery Type | — | Land, Air, Ship | — |
| Wire Size (Dia.) | — | — | 2 - 5.51 mm |
| Input Supply | — | — | 415 V/3P/50 - 60hz |
| Power Req. | — | — | 25 - 45 Kw |
| Weight | — | — | 226 Kg - 275 Kg |
| Usage | — | — | Coating & Metalizing |
| Transport Type | — | — | Land / Sea / Air Transport |
Typical applications for Powder Flame Spray Gun across industrial blasting, coating, and surface preparation work.
Powder Flame Spray Gun applies dense metallic or carbide coatings on high-wear parts.
EnquireSprayed zinc, aluminum, or alloy coats protect structural steel.
EnquireUndersize shafts and housings are rebuilt to print.
EnquireRepeatable spray parameters coat batches of the same part.
EnquireSeats and sleeves get hardfacing for erosion service.
EnquireProcess rolls receive a wear or release surface.
EnquireLocal spray rebuilds damage cheaper than a new part.
EnquireA sealer is applied over porous spray deposits when specified.
