Corrosion Coatings
Molybdenum Wire is sprayed to protect steel structures and vessels.
EnquireWire
Molybdenum wire is a type of wire made from molybdenum, a chemical element with the symbol Mo and atomic number 42. Molybdenum is a silvery-white metal with a high melting point, making it useful for applications that require high-temperature resistance.
Browse full product photos, component close-ups, and application views.
Review the key product specifications used for quotation and application planning.
Watch how the machine performs in real blasting and surface preparation conditions.
Molybdenum wire is a type of wire made from molybdenum, a chemical element with the symbol Mo and atomic number 42. Molybdenum is a silvery-white metal with a high melting point, making it useful for applications that require high-temperature resistance.
Molybdenum Wire is matched to the coating chemistry the job requires.
Wire is fed through the flame or arc spray gun drive rolls.
Flame or electric arc melts the wire as it reaches the nozzle.
Compressed air sprays molten droplets onto the prepared substrate.
Passes overlap until the specified coating thickness is reached.
Bond, texture, and thickness are checked before the part ships.
Molybdenum wire is a type of thermal spray wire made from molybdenum, a chemical element with the symbol Mo and atomic number 42. Molybdenum is a silvery-white metal with a high melting point, making it useful for applications that require high-temperature resistance.
Molybdenum is one of the most well-known and commonly utilized refractory metals, with a melting point of 2622" C (472O"F). Molybdenum wire is employed in various applications that require its particular qualities in the form of wire. These characteristics include high-temperature strength, limited thermal expansion, and a high melting point. Molybdenum has a low vapor pressure, good electrical conductivity, and is reasonably easy to process and shape.
Molybdenum wire is commonly used in the manufacturing of electronic components, such as filaments for vacuum tubes and cathodes for electronic displays. It is also used in the lighting industry for halogen lamps and in the production of heating elements for high-temperature furnaces. It is delivered in either self-contained coils or wound on transportation containers such as spools, reels, or bands. The product is offered in diameters ranging from 2.0 to 250 mils. Sizes ranging from 1 mil to 2.0 mils are only available on special orders. Rod is commonly defined as sizes bigger than 250 mils or cut lengths greater than 20 mils in diameter and greater than 12 inches in length. Fabricated pieces are cut lengths of less than 12 inches in any diameter.
During molybdenum coating, a 1/8" molybdenum alloy wire is dissolved by fire in a wire flame spray gun or HVOF gun fire showering and finely pounded on the workpiece with squeezed air.
According to DIN 55928 section 4, the particles in molybdenum coating form a fine to more grounded microporous coating on the workpiece that has been pre-treated by sand blasting machine SA3. By molybdenum coating, the surface becomes exceptionally retentive and can also be corrected for concealed erosion reasons. A porous, oil-retaining covering has crisis-running properties in the hydrodynamics, design, and vehicle industries, but it is not always required.
Molybdenum wire is known for its strength, flexibility, and resistance to corrosion and wear. It is available in a variety of diameters and can be used for a wide range of applications, including welding, cutting, and brazing.
Molybdenum wire is also used in the production of wire mesh for sieving and filtering applications. It is often preferred over other materials because of its durability and resistance to harsh chemicals. Overall, molybdenum wire is a versatile and useful material that can be found in a variety of industries and applications.
Type R molybdenum wire is made of high-purity (99'95% min.) molybdenum, making it ideal for a variety of fabrications and applications. As customer applications get strict, product and processing requirements become more stringent and, as a result, more expensive.
KW molybdenum wire is constructed from the same high-purity material as KW molybdenum wire but has undergone further treatment to provide a higher recrystallization temperature and approximately 40% higher tensile strength at elevated temperatures. This product is particularly suitable in applications that demand recrystallization retardation, better tensile strength at hotter temperatures, and a higher degree of room temperature stiffness. After cycling through increased temperatures, KW moly wire exhibits better room temperature ductility than Type R.
Spray Blast is one of the best Molybdenum Wire manufacturers & Suppliers of thermal spray wire, Alloy 625 wire, metalizing wire, aluminum wire, zinc wire, copper wire, molybdenum wire, thermal spray gun, arc spray gun, flame spray gun, metalizing gun, abrasive media, sand blasting machine, sand blasting cabinet, etc.
Compare Molybdenum Wire with other models in Wire.
| Specification | Metalizing Wire | This model Molybdenum Wire | Alloy 625 Wires |
|---|---|---|---|
| Material | Zinc, Aluminium | Molybdenum | — |
| Diameter | 6.00 mm To dia 1.20 mm. | — | 10 mm To 100 mm |
| Weight | 44lbs (20kgs) 450lbs (204kgs) | — | — |
| Packaging Size | 1/16"(1.6mm) (2mm) 3/32"(2.3mm) 1/8"(3.2mm) 3/16"(4.8mm) | — | — |
| Brand | Spray Blast | Spray Blast | Spray Blast |
| Country | India | India | India |
| Packaging | Spool Drum | — | — |
| Color | Silver | Black | — |
| Delivery Time | 5-7 Days | 5-7 Days | 1 Weeks |
| Transport Type | Land / Sea / Air Transport | Land / Sea / Air Transport | — |
| Price Range | Rs 350 - 7900 /kg | Rs 5K /Kg - 8K /Kg | Rs 200 - 350 /kg |
| Product | — | Molybdenum Wire | — |
| Sizes | — | 0.1mm to 50mm | — |
| Density | — | 10280 kg/㎥ | 8.4 g/cm3 |
| Melting Point | — | 2600 Degree | 1.350 °C (2460 °F) |
| Purity | — | 99.95% | — |
| Length | — | As per requirement | — |
| Packaging Details | — | Wooden Box | — |
| Tensile Strength | — | — | Psi – 1,35,000 , MPa – 930 |
| Minimum Order Quantity | — | — | 40 Kg |
| Production Capacity | — | — | 10 Tons |
Typical applications for Molybdenum Wire across industrial blasting, coating, and surface preparation work.
Molybdenum Wire is sprayed to protect steel structures and vessels.
EnquireWorn shafts or housings are built up with sprayed alloy.
EnquireA sprayed layer keys later ceramic or carbide coats.
EnquireProduction parts receive a consistent sprayed metal film.
EnquireField metallizing restores large steel assets.
EnquireSelected wires are used where sparking risk must stay low.
EnquireBabbitt and similar alloys rebuild white-metal surfaces.
EnquireNickel or molybdenum wires coat parts that see heat.
EnquireAnswer a few questions and we will suggest a starting configuration for Molybdenum Wire — then confirm the exact specification with our team.
